Heavy Duty Jib Crane
Overview

Column is made of seamless steel pipe, and the main girder is made of 1-beam girder or KBK light beam, rotating way can be manual(< 1t) or electric. JIB crane can be equiped electric wire rope hoist, electric chain hoist or manual hoist. It is suitable to work in the short-range and intensive lifting occasions. So it's widely used in workshops, warehouses, docks and other fixed place.
We can recommend different models of cranes according to different working requirements. This kind of machine has two types of manipulation: electric and manual operation. Rotary arm rotation angle can be chosen from 180 °, 270 °, 345 °, 360 ° according to client's usage.
Products Parameter

|
Lift capacity(T)
|
1, 2, 3, 5, 10, 16, 20
|
|||
|
Span(M)
|
7.5-22.5
|
|||
|
|
speed(m/min)
|
10, 20, 30
|
45, 60
|
|
|
|
type
|
ZDY1 21-4
|
ZDR12-4
|
|
|
power(kw)
|
2*0.8
|
2*1.5
|
||
|
speed(r/min)
|
1380
|
1380
|
||
|
Electric chain hoist or wire rope hoist
|
model
|
CD1/MD1/HHBB
|
||
|
lift height(m)
|
3-25
|
|||
|
traversing speed(m/min)
|
20,30 or can be customized
|
|||
|
lifting speed(m/min)
|
8(7); 8/0.8(7/0.7)
|
|||
|
Workclassfication
|
A3-A5
|
|||
|
Power supply
|
380V/50HZ or on request
|
|||
Product Features
1. Material: High-quality steel structure, not easy to rust, easy to maintain in the future;
2. Structure: It consists of a column, a swing arm slewing device and an electric hoist. It has light weight and large span;
3. Simple operation, large lifting capacity, energy saving and trouble-free;
4. Customized production according to customer needs, easy to install.
Products Details

Application Scenarios

Company Profile
