Column mounted slewing jib crane is a small and medium-speed lifting equipment developed recently . It has characteristics of unique structure , safe and reliable operation , high , efficiency , energy-saving , effort-saving , and flexibility . It can be operated under three dimensional environment .

Send Inquiry

Chat Now

Product Introduction

Overview

jib crane

Jib crane work for light intensity, crane by post, rotating arm rotation drive device and electric hoist, column bottom through on the concrete foundation with anchor bolt, cantilever rotary driven by cycloidal pinwheel reducer, electric hoist on the cantilever beams as a straight line running from left to right, and lifting heavy objects. Jib crane for hollow steel structure, light weight, big span, lifting weight, economy and durable.

Products Parameter

jib crane drawing

ITEM		Specifications
Capacity	t	0.5	1	2	3	5	10	16	20
Arm length	m	1.2~20
Lifting height	m	1~15
Lifting speed	m/min	3.5 / 7 / 8
Travelling speed	m/min	20 / 30
Rotate speed	r/min	0.7
Rotate angle	degree	360°
Wire rope	mm	Ø4.7	Ø7.7	Ø11	Ø13	Ø15.5	Ø15.5	Ø17.5	Ø22.5
Power source		3-phase, 380v50Hz OR as required

Safety Features

Full set of safety protection equipment:weight limit,moment limit,height limit, and slewing limit,emergency brake, labor protective devices like rest platform and guardrail.
1.Weight limit: If the material is over the capacity, the crane will give a sharp warning for protection itself.
2.Moment limiter:Real-time monitoring and detection of crane working conditions, with its own diagnostic function, rapid dangerous status alarm and safety control.
3.Height limit:Control the lowest and highest extreme position of lifting hook.
4.Slewing limit: Control the extreme turns number of turn left and right.
5.Emergency brake: If the operation staff encounter some emergency situation, we could start the emergency brake system to protection the related treasure.
