A 10-ton gantry crane is an industrial lifting machine with a lifting capacity of 10 tons. It is typically used to handle heavy loads in outdoor environments, such as shipping ports, construction sites, or factory yards. A gantry crane is designed with a horizontal steel beam that is supported by two or more uprights, which are mounted on wheels or fixed to the ground.

Send Inquiry

Chat Now

Product Introduction

Products Description

10t

The 10-ton gantry crane consists of several key components, which include the bridge, hoist, trolley, runway beams, and legs. The bridge is the horizontal beam that spans the distance between the uprights, and the hoist is the lifting mechanism that is mounted on the bridge and used to lift and lower loads. The trolley is the mechanism used to move the hoist horizontally along the length of the bridge, while the runway beams provide support for the trolley and hoist. The legs are typically comprised of vertical steel columns and provide stability and support for the gantry crane.

Technical Data

Lifting capacity	10 tons
Span	20m - 35m
Lifting height	6m - 12m
Lifting speed	3-8m/min (single speed or dual speed)
Trolley traveling speed	20-30m/min
Crane traveling speed	30-45m/min
Power supply	AC 3-phase, 220-480V, 50/60Hz
Operating temperature	-20℃ to +40℃
Control method	pendant control, wireless remote control
Duty cycle	A5 (medium duty)

The technical data may vary depending on the specific design and manufacturer of the gantry crane. It is important to consult with a reputable supplier to determine the technical data required for the specific application. Additionally, regular maintenance and inspections are important for safe and efficient operation, and should be carried out in accordance with manufacturer's instructions.
